AUSA · Articulated Dumper
AUSA D1001APG Dumper
Description
The Heavy-Duty Dumper For Maximum Performance
Cost-effective, safe and high-tech. It is equipped with a 180-degree swing skip and has a 22,000-lb payload, making it AUSA’s highest-payload articulated dumper. Its transmission includes a converter that ensures fast power delivery and speed.
The D1001APG dumper is easy to maintain because all components are designed to minimize downtime. One option is a Smart Stop, which turns off the engine when it is not in use. This will significantly reduce fuel consumption, maintaining low CO2 emissions.
Features & Benefits
Heavy-duty dumper with power & speed
Closed ROPS/FOPS cab with heating and air conditioning
Large articulating dumper bucket
Big performance for big jobs
Fuel efficiency with low maintenance
Anti-vandal security system
Three rear-view mirrors
All-in-one joystick
Specifications
AUSA D1001APG Dumper Specifications
Operating Weight11,360 lbs.
Unloading SystemSwivel tip
Weight Load Capacity22,000 lb
ChassisArticulated
Heaped Skip Capacity5.1 cu yd / Level Skip Capacity 4.32 cu yd
TransmissionPower shuttle
Max. Speed15.5 mph
Maximum Gradient45 %
External Turning Radius247 in.
Traction4x4
Tires500/60-22.5
Fuel Capacity18.2 gallons
Engine Options
ModelPowerEmissions
Deutz TCD 3.6 L4 HT74.3 hpStage IIIB - EPA Tier 4F
