AUSA ยท Articulated Dumper
AUSA D601APG Dumper
Description
More Power & Speed With A Large Payload
Cost-effective, safe and high-tech. It has an 180-degree swing skip, a 13,200-lb payload, and a torque-converter transmission for quicker power delivery and higher speed. With the D601APG, the dumper is easy to maintain and can be equipped with Smart Stop, which switches off the engine when not in use, significantly reducing fuel consumption and keeping CO2 emissions low.
Additionally, a digital display is built into the driver’s console, where you will find real-time information about the machine, such as speed, RPM, fluid levels, and alarms.
Features & Benefits
Optional fuel-efficient features
Closed ROPS/FOPS cab with heating and air conditioning
Real-time readouts in the console
Easy maintenance accessibility
Acoustic warning for reverse gear
Fully articulating dumper
Adjustable ergonomic seat
All-in-one joystick
Specifications
AUSA D601APG Dumper Specifications
Operating Weight10,240 lbs.
Unloading SystemSwivel tip
Load Weight Capacity13,200 lbs.
ChassisArticulated
Heaped Skip Capacity4.12 cu yd/ Level Skip Capacity 3.21 cu yards
TransmissionPower shuttle
Max. Speed15.5 mph
Maximum Gradient45 %
External Turning Radius232 in.
Traction4x4
Tires405/70-20
Fuel Tank18.2 gallons
Engine Options
ModelPowerEmissions
Deutz TD3.6 L474.3 hpStage IIIB - EPA Tier 4F
