AUSA · Articulated Dumper
AUSA DR1001AHG Dumper
Description
Heavy-Duty Workhorse Dumper For Tight Jobsites
The DR1001AHG reversible dumper features a 22,000-lb payload and a comfortable hydrostatic transmission. Thanks to the innovative reversible design, the seat can rotate 180 degrees, and all components are instantly adjusted to suit the driver’s new position. The driver can also comfortably and safely get on and off the dumper from both sides, significantly increasing speed and flexibility.
It has an ECO Mode function that automatically adjusts engine speed to reduce fuel consumption and CO2 emissions. The Hill Holder system is a start-assist and safety feature that applies the dumper’s brakes when you take your foot off the accelerator at zero speed. This significantly increases safety, especially when operating on slopes.
Features & Benefits
Reversible driving positions for great safety in tight spaces
Large articulating dumper bucket
Closed ROPS/FOPS cab with heating and air conditioning
Safety in tight area jobsites
Camera on the skip side
All-in-one joystick
Hill Holder - hill-start assist
Specifications
AUSA DR1001AHG Dumper Specifications
Operating Weight11,133 lbs.
Weight Load Capacity22,000 lbs.
Unloading SystemSwivel tip
ChassisArticulated
ReversibilityReversible
Heaped Skip Capacity3.1 cu yd
TransmissionHydrostatic
Max. Speed13.7 mph
Maximum Gradient45 %
External Turning Radius247 in
Traction4x4
Tires500/60-22.5
Fuel Tank18.2 gallons
Engine Options
ModelPowerEmissions
Deutz TCD3.6 L4 HT74.3 hpStage IIIB - EPA Tier 4F
