Anaconda · Tracked Jaw Crusher

Anaconda J12 Jaw Crusher

A direct-hydraulic-drive jaw chamber built for primary crushing — rock, recycled concrete, and the abrasive material that wears lesser machines out.

High-Performing Crushing On Tracks

The Anaconda J12 Jaw Crusher is a versatile primary crushing solution designed to process abrasive materials such as basalt, granite, recycled concrete, and virgin rock. The J12 Jaw Crusher utilizes an extremely fuel-efficient and powerful hydraulic system that enables the machine to deliver excellent productivity and comes standard with fully hydraulic chamber adjustment, tramp release, and reset. The direct hydraulic drive enables reverse operation to prevent uncrushable material from entering the chamber and offers an adjustable closed side setting (CSS) for ultimate control over final product size.

Features & Benefits
Hydraulically folding wing plates
Hydraulic toggle and tension rod setup
Variable-speed side conveyor
Overband magnet with dual-side discharge
Vibrating grizzly feeder
Quick setup and breakdown in 20 minutes or less
Radio remote control
Optional Features Hopper extensions · Belt scale · Deflector plate under jaw · Super-tooth, multi-tooth & 35/55 mm corrugated jaw dies · Light mast & cabinet lights

Anaconda J12 Jaw Crusher Specifications

Overall Height12' 7"
Length47'
Width7'
Weight100,000 lbs
Hopper Capacity8.5 yd³
Crushing Chamber44" x 28"
Closed Side Setting*2″ – 7.5″
Jaw Speed250 – 280 rpm
*CSS range is dependent on material feed size, material friability and wear

Engine Options

ModelPowerEmissions
Cummins IPU L9 380283 kW / 380 HPTier 3
CAT 9.3 LRC310 kW / 416 HPTier 3
Cummins IPU L9 380283 kW / 380 HPStage V
CAT 9.3310 kW / 416 HPStage V

Let's Talk Tonnage

Tell us your material, your output target, and your timeline — we'll spec the right configuration and talk purchase, rental, or rent-to-own.
