ASV · Compact Track Loader
ASV RT-40 Compact Track Loader
Description
Exceptional Power & Performance Come Standard
With a compact frame and maximum power, the RT-40 provides a productive alternative to walk-behind and stand-on mini skid-steer loaders. And with its reliability, serviceability, and comfort, it’s ideal for homeowners and contractors looking to accomplish a lot in small spaces.
Built for performance, this 4’ wide powerhouse features a turbocharged YANMAR diesel powerplant. The 1.6-liter-displacement engine produces 93.6 foot-pounds of torque, providing high tractive effort thanks to ASV’s Posi-Power system—enabling exceptional pushing and digging power. The ASV RT-40 compact track loader is engineered to deliver minimal ground pressure, topping out at 7.1 MPH and reaching an impressive 8.4-foot lift height.
Features & Benefits
Convenient push-to-connect quick couplers mounted on the manifold block to save time
Manual quick attach
Back-up Alarm
2 independent torsion axles per undercarriage for more stability
Minimal ground pressure to ensure less ground disruption
Easy access to components to eliminate high labor repair costs
Specifications
ASV RT-40 Compact Track Loader Specifications
Operating Weight4,005 lbs.
Overall Height7.5 in.
Rated Operating Capacity (35%)931 lbs
Ground Pressure3.3 psi
Ground Clearance10.8 in.
Power38.2 hp
Track Width11 in.
Max. Travel Speed7.1 mph
Fuel Tank10 gallons
Engine Options
ModelPowerEmissions
YANMAR 3TNV86CT38.2 hp (28.5 kW)Tier 4 Final
