Terex TRT 55US Rough Terrain Crane

Rough Terrain Crane

Solid Mid-Sized Crane For Multiple Applications

The new Terex rough terrain crane, TRT 55US, is a 55 USt maximum capacity crane with a main boom length of 123 ft. The model features the new TEOS Terex Operating System, which is displayed on a 10-inch touch screen. This new control system boasts a completely redesigned user interface with enhanced information flow and accessibility, aimed at increasing customer operating efficiency. Terex Rough Terrain cranes, with excellent ground clearance and up to four steering modes, enable positioning in the most rugged terrain and make the task easy for certified crane operators.  Terex RTs are noted for their legendary durability and low cost of ownership. This is why Terex rough-terrain cranes are the ideal choice for day-in, day-out lifting.

Features & Benefits
Easy maneuverability
Four steering modes for different jobsites
Wide range of options for different applications
123.0 ft maximum hook height
Environmental operator’s cab optimizes load visibility and productivity
Extra-wide and tiltable cabin
Ergonomic and customizable electro-proportional joysticks
Compact dimensions

Terex TRT 55US Rough Terrain Crane Specifications

Overall Vehicle Weight62,170 lbs.
Max Lifting Capacity55 US tons @ 8.2 ft radius
Main Boom31.2 – 122.7 ft. (5-section)
Max Tip Height (Main Boom):130 ft (incl. extension)
Max Tip Height (with Jib): 26.2 ft (offsets 0° / 20° / 40°)
Transmission4WD with two shift modes
Engine Power173 hp @ 2,200 rpm
Counterweight12,100 lbs.
Travel Speed18.3 mph
Steering: Four modes (two-wheel front, two-wheel rear, four-wheel coordinated, four-wheel crab)
Fuel Tank79 gallons

Engine Options

ModelPowerEmissions
Cummins QSB6.7 173 hp.(Tier 3)
